Steel Materials

• 11ga Shell
• 12ga Toolboxes
• 3in Channel (Crossmembers)
• 4in Channel (Frame Runners)
• 3/8" Rub Rails (Sides)
• 1/4" Stake Pockets

Standard Specs

• DOT Approved Lighting
• Angled Fuel Fill
• High Durability Industrial Paint (sandblasted and primed) (Standard)
• Bare Aluminum (Standard)

Curt Universal Weld-On Receiver
(20 000lbs GTW)

• 2.5in Receiver Tube
• Class 5 hitch
• Tested for safety in accordance with SAE J684

Recessed Gooseneck Well
(30 000lbs GTW)

• 30 000 lbs GTW gooseneck Ball (2-5/16") Curt #40088

• Compatible with our Well DSP 5th wheel companion kit (32,000 lbs GTW)

B&W Turnover Ball Top Plate
(30 000lbs GTW)

• Compatible with our Top Plate DSP 5th wheel companion kit
  (32,000 lbs GTW)
• Compatible with B&W 5th Wheel Hitch B&W 'COMPANION' Flatbed kit
  (22, 000 lbs GTW)

B&W 'COMPANION' Flat Bed version
(22 000lbs GTW)

• Quiet Ride, Easy to operate, Adjustable
• Gross Pin Weight: 5500 Pound
• 1" thick jaws
• Mounts into the turnover ball slot

DSP Falcon 5th Wheel (Top Plate)
(32 000lbs GTW)

• Heavy duty construction for light duty commercial, farming & frequent towing usage
• 1" thick jaws
• Lock-out pin to ensure jaws are engaged for towing
• Bolts into top plate using the 6x 0.75" built in holes

BW Turnover + Flip DSP 5th Wheel
(32 000lbs GTW)

• 30 000 lbs GTW B&W Gooseneck Turnover Ball
• DSP Fifth Wheel (32 000lbs GTW)

7in Side Rails

• Bent side rails
• 11 ga steel | 1/8" aluminum

12in Side Rails

• 1.5x1.5in Square tubing design

• 1.5in gap for straps in side rails

3366 (2x3in | 2x6in)

Drawer Internal Dimensions
Depth: 20"
Width (Normal):20.625"
Width (Short Box): 14.625"

33 (2x3in)

Drawer Internal Dimensions
Depth: 20"
Width (Normal):20.625"
Width (Short Box): 14.625"

666(3x6in)

Drawer Internal Dimensions
Depth: 20"
Width (Normal):20.625"
Width (Short Box): 14.625"

333333 (6x3in)

Drawer Internal Dimensions
Depth: 20"
Width (Normal):20.625"
Width (Short Box): 14.625"

Half Packs

Lower Packs

Not available in shortboxes
